YETC Series Fastening Torque Controller

Product Code:  YETC-200, YETC-3A
Brand Name:    Yokota




Specification


YETC-200
  • *Dimension: 230mm (W) x 110mm (H, including rubber foot) x 290mm (D, excluding projection) (YETC-200)
  • Weight: 5.2 kg
  • Applicable voltage: AC100V - 240V±10%50Hz60Hz
  • Power consumption: 30W
YETC-3A
  • *Dimension: 200mm (W) x 108mm (H, including rubber foot) x 185mm (D, excluding projection) (YETC-3A)
  • Weight: 2.8 kg
  • Applicable voltage: AC100V±10%
  • Power consumption: 30W (Option) AC100V - 240V Applicable
  • Tool cable (optional): 5m, 7m, 10m, etc.
  • Connecting tool: 1 or 2 (Optional)

*Parameters differ with input values when work is different.





Features


1. Parameters
  • Preliminary torque, Min. torque, Cut torque, Max. torque
  • Skip No., Fast abnormal (Double hit detection)
  • Cycle abnormal (Slow error), Compensation No.
  • Bolt count mode (Relay-ON time)
  • Co-efficient, Average No., Judging time etc..
2. Test Mode
  • Static torque mode, Dynamic torque mode
3. Input terminal
  • 8 points
4. Output terminal
  • Relay output 8 (YETC-200), 10 (YETC-3A) : No voltage contact output
  • Solenoid valve output : AC voltage 1, DC24V 2
  • Printer output : Centronics standard (YETC-200)
  • Serial output : RS-232C
